杰亦洋代理茂仁ME-8108限位開關
|
|
|
|
| |
 小型橫式限制開關 (Made in Taiwan) | |
|
 |
FIELD ADJUSTABLE : |
| |
Rotary motion roller lever and rod actuators are adjustable
through 360°. They may be set for operation clockwise, counter-clockwise, or in both directions. Operating heads may be positioned in any of four 90° positions. |
| |
|
|
EASY WIRING : |
| 1. |
Loosen cover screws and remove cover. |
| 2. |
Remove rubber strain relief from switch cover. |
| 3. |
Slip strain relief over cable. |
| 4. |
Fasten terminal screws and grounding screw tightly after inserting cables or terminals. |
| 5. |
After wiring insert strain refief into the groove of the switch cover. |
| 6. |
Fasten 3 cover screws evenly. Do not over tighten. |
| 7. |
Recommended Cable-# 18/3 SJT Flexible. | |
 | |
|
|
|
|
特性 : |
| |
| Operating speed |
0.5mm to 50m/sec |
| Operating frequency |
Mechanically:120 operations/min.
Electrcally:30 operatioms/min. |
| Contact resistance |
15m  max.(initial) |
| Insulation resistance |
100M min,(at 500 VDC) |
| Dielectric strength |
1,000VAC. 50/60 Hz for 1 minute between non-continuous terminals
2,000VAC. 50/60 Hz for 1 minute between each terminal and non-current carrying metal part and between each terminal and ground. |
| Vibration |
Malfunction durability:10 to 55 Hz;
1.5mm double amplitude. |
| Shock |
Mechanical durability:
Approx. 1,000m/sec2 (approx.100G s)
Malfunction durability :
Approx.300m/sec2 (approx.30G s) |
| Ambient temperature |
Operating : -15 to +70 |
| Humidity |
95% RH max |
| Service life |
Mechanically: 10,000,000 operations min
Electrically: 300,000 operations min,(2A,110VAC)MAX. |
| Degree of protection |
IEC 529 class IP65 | |
| |
| |
 | |
|
|
|
|
ORDER GUIDE |
| |
 標準型
| ME-8104 |
ME-8107 |
ME-8018 |
ME-8111 |
ME-8112 |
| ME-8122 |
ME-8166 |
ME-8169 |
ME-9101 |
ME-8000 |
金屬滾輪 (定製品)
 50mm 橡膠滾輪 (定製品) : 50mm
塑膠滾輪 (定製品)
動作柄1/4白鐵 3/4 彈簧(定製品)
|
| |
|
|
REMARK : |
| |
金屬滾輪型式 :
塑膠滾輪型式 :
50mm 橡膠滾輪型式 :
動作柄1/4白鐵 3/4 :
| ME-9101-HI |
→ 1/4 steel and 3/4 spring |
|
| |
|
| |
| |
 | |
